| cooling | 14.00 kW |
|---|---|
| Heating | 15.00 kW |
| Capacity | cooling | kW | 14.00 |
| heating | kW | 15.00 | |
| Power supply | ~380-415V/50Hz/1Ph | ||
| Power input | cooling | kW | 5.00 |
| heating | kW | 4.40 | |
| Current | cooling | А | 8.60 |
| heating | А | 7.60 | |
| Energy efficiency | cooling | EER | 2.80 |
| heating | COP | 3.41 | |
| Air flow | m³/h | - | |
| Sound pressure level | IDU | dB(А) | - |
| Sound pressure level | ODU | dB (А) | 59 |
| Refrigerant type | R410a | ||
| Overall dimensions (W/H/D) | IDU | mm | 840/290/840 |
| IDU panel | mm | 950/-/950 | |
| ODU | mm | 940/820/460 | |
| Weight | IDU/ODU | kg | /96 |
| Refrigerant charge | kg | 3.7 | |
| Temperature range | cooling | °C | -15 ... +48 |
| heating | °C | -20 ... +24 | |
| Liquid connection diameter | mm/inch | 9.53/3/8” | |
| Gas connection diameter | mm/inch | 15.88/5/8” | |
| Max. height | m | 30 | |
| Max. length | m | 75 | |
| Distance between ODU mounting bolts | mm | 610 | |
| Interblock wired cords number (control) | 2*0.75 – length < 20 m 2*1.0 – length > 20 m |
||
| Main power point | ODU | ||
| Wired cords quantity (power supply IDU/ODU) | IDU | 3(Ø1.0 mm) | |
| ODU | 5(Ø1.5 mm) | ||
| Factory refrigerant charge (meters) | m | 7.5 | |
| Refrigerant charge per meter) | g/ m | 50.0 | |
