| Capacity |
Cooling |
kW |
5,00 |
| Heating |
kW |
5,50 |
| Electric power supply |
~220-240 V/50 Hz/1 Ph |
| Rated input |
Cooling |
kW |
1,56 |
| Heating |
kW |
1,65 |
| Energy performance |
Cooling |
EER |
3,21 |
| Heating |
COP |
3,33 |
| Air flow |
Indoor unit |
m³/h |
700 |
| Sound-pressure level |
Indoor unit |
dB (A) |
44/39/36/33 |
| Outdoor unit |
dB (A) |
53 |
| Type of refrigerant coolant |
R32 |
| Volume of refrigerant coolant |
kg |
1,00 |
| Weight |
Indoor unit |
kg |
17 |
| Panel |
kg |
3 |
| Outdoor unit |
kg |
39 |
| Operational temperature range |
Cooling |
°C |
-20~48 |
| Heating |
°C |
-20~24 |
| Liquid piepeline diameter |
mm/inch |
6,38/1/4" |
| Gas piepeline diameter |
mm/inch |
12,70/1/2" |
| Maximum piepeline level difference |
m |
20 |
| Pipeline maximum length |
m |
35 |
| Number of interblock strands (for control) |
|
mm² |
2х0,75 |
| Main power supply area |
Outdoor unit |
| Number of the strands (power supply) |
Indoor unit |
3 (∅ 1,0mm²) |
| Outdoor unit |
3 (∅ 1,5mm²) |
| Factory Freon fill ( for the number of the running meters) |
m |
5 |
| Freon per one running meter (surplus. for one running meter) |
g/m |
16 |
| SEER/SCOP |
5,90/4,00 |
| Energy performance class |
А+/А+ |
